F7200224 -------- TECHNICAL DATA --------   Power
consumption 360W - 5x72W Amber LEDs Power supply voltage 90 -
240V Voltage frequency 50/60Hz Display LCD Matrix Number
of diodes 5 -------- UTILITY DATA --------   Beam angle
(min) 120° Beam angle
(max) 120° Dimming Linear: 0 - 100% Flash frequency
(min) 1Hz Flash frequency (max) 20Hz Number of DMX
channels 5/7/10 DMX standard DMX 512 Control interface Wheel
controller Operating modes DMX512, Manual, Auto, Sound-controlled,
Master / Slave, RDM -------- INTERFACES --------   AC
IN powerCON TRUE1 AC OUT powerCON TRUE1 DMX IN XLR - 3
pin DMX OUT XLR - 3 pin ----- PHYSICAL CHARACTERISTICS
-----   IP Rating IP65 Housing
made Aluminum Cooling Active Height [cm] 9,5 Width
[cm] 100,4 Depth [cm] 13 Weight [kg] 9,5
